T SERIES (G3) 3-PHASE INVERTERS
The T Series inverter range is aimed at 3-phase domestic and small-scale commercial installations, offering unrivalled performance and versatility for increased yield potential and longer generation windows. The 3-phase T Series inverter options range from 3kW to 25kW.
| Parameter |
T3-G3 |
T4-G3 |
T5-G3 |
T6-G3 |
T8-G3 |
T10-G3 |
T12-G3 |
T15-G3 |
T17-G3 |
T20-G3 |
T25-G3 |
T23-G3 |
| Max. Input Power [W] |
4500 |
6000 |
7500 |
9000 |
12000 |
15000 |
17000 |
20000 |
25000 |
– |
– |
34500 |
| Max. Input Voltage [V] |
1100 |
1100 |
1100 |
1100 |
1100 |
1100 |
1100 |
1100 |
1100 |
– |
– |
1100 |
| Start-up Input Voltage [V] |
140 |
140 |
140 |
140 |
140 |
140 |
140 |
140 |
140 |
– |
– |
140 |
| Rated Input Voltage [V] |
600 |
600 |
600 |
600 |
600 |
600 |
600 |
600 |
600 |
– |
– |
600 |
| MPPT Operating Voltage Range [V] |
140–1000 |
140–1000 |
140–1000 |
140–1000 |
140–1000 |
140–1000 |
140–1000 |
140–1000 |
140–1000 |
– |
– |
140–1000 |
| Max. Input Current [A] |
14 |
14 |
14 |
14 |
14 |
14 |
28 |
28 |
28 |
– |
– |
28 |
| Max. Short-circuit Current [A] |
18.2 |
18.2 |
18.2 |
18.2 |
18.2 |
18.2 |
36.4 |
36.4 |
36.4 |
– |
– |
36.4 |
| No. of Independent MPP Trackers |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
– |
– |
2 |
| Strings per MPP Tracker |
1+1 |
1+1 |
1+1 |
1+1 |
1+1 |
1+1 |
2+2 |
2+2 |
2+2 |
– |
– |
2+2 |
| Parameter |
T3-G3 |
T4-G3 |
T5-G3 |
T6-G3 |
T8-G3 |
T10-G3 |
T12-G3 |
T15-G3 |
T17-G3 |
T20-G3 |
T25-G3 |
T23-G3 |
| Rated Output Power [W] |
3000 |
3300 |
4000 |
4400 |
5000 |
5500 |
6000 |
6600 |
7500 |
8800 |
10000 |
23000 |
| Max. Output Apparent Power [VA] |
3300 |
3960 |
4400 |
5060 |
5500 |
5830 |
6000 |
6600 |
7500 |
8800 |
10000 |
25300 |
| Rated Grid Voltage [V] |
3/N/PE, 220/380, 230/400, 240/415 |
Same for all |
|
|
|
|
|
|
|
|
|
|
| Rated Grid Frequency [Hz] |
50/60 |
Same for all |
|
|
|
|
|
|
|
|
|
|
| Rated Output Current [A] |
4.3 |
4.8 |
5.8 |
6.4 |
7.2 |
8.0 |
8.7 |
9.6 |
11.6 |
12.8 |
14.5 |
33.3 |
| Max. Output Current [A] |
4.8 |
5.3 |
6.4 |
7.0 |
8.0 |
8.8 |
9.6 |
10.5 |
12.8 |
14.2 |
15.9 |
36.7 |
| Power Factor |
1 (Adjustable 0.8 leading ~ 0.8 lagging) |
Same for all |
|
