S700-G3 / S1000-G3 / S1500-G3 / S2000-G3 / S2500-G3 / S3000-G3 / S3300-G3
S SERIES (G3) SINGLE MPPT INVERTERS
Offer a range of single MPPT single-phase inverters offering unparalleled efficiency and performance. Our range starts with the S700-G3 - small and compact and with an ultra-low start-up voltage that will ensure you harvest the most energy possible from your solar panels.
| 3KW |
19800 |
| 5 KW |
33000 |
| 6 kva |
35500 |
| Model |
S700-G3 |
S1000-G3 |
S1500-G3 |
S2000-G3 |
S2500-G3 |
S3000-G3 |
S3300-G3 |
| Max. Recommended DC Power [W] |
1050 |
1500 |
2250 |
3000 |
3750 |
4500 |
5400 |
| Max. DC Voltage [V] |
500 |
500 |
500 |
500 |
500 |
500 |
500 |
| Nominal DC Operating Voltage [V] |
360 |
360 |
360 |
360 |
360 |
360 |
360 |
| Max. Input Current [A] |
16 |
16 |
16 |
16 |
16 |
16 |
16 |
| Max. Short Circuit Current [A] |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
| MPPT Voltage Range [V] |
50–480 |
50–480 |
50–480 |
50–480 |
50–480 |
50–480 |
50–480 |
| MPPT Voltage Range (Full Load) [V] |
80–450 |
110–450 |
160–450 |
210–450 |
240–450 |
280–450 |
300–450 |
| Start-up Voltage [V] |
60 |
60 |
60 |
60 |
60 |
60 |
60 |
| No. of MPP Trackers |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| Strings per MPP Tracker |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
⚡ AC Output
| Parameter |
S700-G3 |
S1000-G3 |
S1500-G3 |
S2000-G3 |
S2500-G3 |
S3000-G3 |
S3300-G3 |
| Nominal AC Power [W] |
700 |
1000 |
1500 |
2000 |
2500 |
3000 |
3300 |
| Max. AC Apparent Power [VA] |
800 |
1100 |
1650 |
2200 |
2750 |
3300 |
4000 |
| Rated Grid Voltage [Vac] |
220/230/240 |
220/230/240 |
220/230/240 |
220/230/240 |
220/230/240 |
220/230/240 |
220/230/240 |
| Rated Grid Frequency [Hz] |
50/60 |
50/60 |
50/60 |
50/60 |
50/60 |
50/60 |
50/60 |
| Nominal AC Current [A] |
3.0 |
4.3 |
6.5 |
8.7 |
10.9 |
13.0 |
14.3 |
| Max. AC Current [A] |
3.5 |
4.8 |
7.2 |
9.6 |
12.0 |
14.3 |
17.4 |
| Displacement Power Factor |
1 (0.8 leading ~ 0.8 lagging) |
|
|
|
|
|
|
| THDi (Nominal Output) |
<3% |
<3% |
<3% |
<3% |
<3% |
<3% |
<3% |
