BiN-17-615 to BiN-17-645
Framed Dual Glass Bifacial module
ELECTRICAL CHARACTERISTICS
| Model |
Pmax (W) |
Vmp (V) STC |
Vmp (V) NOCT |
Imp (A) STC |
Imp (A) NOCT |
Isc (A) STC |
Isc (A) NOCT |
Voc (V) STC |
Voc (V) NOCT |
Module Eff. (%) |
| BiN-17-615 |
615 |
47.27 |
44.06 |
13.01 |
10.51 |
13.78 |
11.12 |
56.55 |
53.72 |
22.00 |
| BiN-17-620 |
620 |
47.44 |
44.21 |
13.07 |
10.56 |
13.83 |
11.16 |
56.71 |
53.87 |
22.18 |
| BiN-17-625 |
625 |
47.60 |
44.36 |
13.13 |
10.61 |
13.88 |
11.20 |
56.88 |
54.04 |
22.36 |
| BiN-17-630 |
630 |
47.73 |
44.48 |
13.20 |
10.67 |
13.94 |
11.25 |
57.02 |
54.17 |
22.54 |
| BiN-17-635 |
635 |
47.89 |
44.63 |
13.26 |
10.71 |
13.99 |
11.29 |
57.18 |
54.32 |
22.72 |
| BiN-17-640 |
640 |
48.01 |
44.75 |
13.33 |
10.77 |
14.05 |
11.34 |
57.33 |
54.46 |
22.90 |
| BiN-17-645 |
645 |
48.17 |
44.89 |
13.39 |
10.82 |
14.11 |
11.39 |
57.49 |
54.61 |
23.07 |
BI-FACIAL OUTPUT - BACKSIDE POWER GAIN*
| Specification |
BiN-17-615 |
BiN-17-620 |
BiN-17-625 |
BiN-17-630 |
BiN-17-635 |
BiN-17-640 |
BiN-17-645 |
| 15% Power Output (W) |
707.25 |
713 |
719 |
725 |
730 |
736 |
742 |
| Module Efficiency (%) |
25.30 |
25.51 |
25.71 |
25.92 |
26.13 |
26.34 |
26.53 |
| 20% Power Output (W) |
738 |
744 |
750 |
756 |
762 |
768 |
774 |
| Module Efficiency (%) |
26.40 |
26.62 |
26.83 |
27.05 |
27.26 |
27.48 |
27.68 |
| 25% Power Output (W) |
768.75 |
775 |
781 |
788 |
794 |
800 |
806 |
| Module Efficiency (%) |
27.50 |
27.73 |
27.95 |
28.18 |
28.40 |
28.63 |
28.84 |
| 30% Power Output (W) |
799.5 |
806 |
813 |
819 |
826 |
832 |
839 |
| Module Efficiency (%) |
28.60 |
28.83 |
29.07 |
29.30 |
29.54 |
29.77 |
29.99 |
THERMAL CHARACTERISTICS
| Specification |
Value |
| Temperature Coefficient of Current (Isc), α (%/ºC) |
0.046 |
| Temperature Coefficient of Voltage (Voc), ß (%/ºC) |
-0.26 |
| Temperature Coefficient of Power (Pm), γ (%/ºC) |
-0.30 |
| NOCT (ºC) |
43 ± 2 |
| Operating Temperature Range (ºC) |
-40 to 85 |
| Bifaciality Factor (%) |
80 ± 10 |
MECHANICAL CHARACTERISTICS
| Specification |
Details |
| Length x Width x Thickness (L x W x T) |
2465 mm (L) x 1134 mm (W) x 35 mm (T) |
| Weight |
34.5 kgs |
| Solar Cells per Module (Units) / Arrangement |
156 cells / (13x6 || 13x6) |
| Solar Cell Type & Size |
M10 / M10R N-type TOPCon Bifacial |
| Front Glass (Material / Thickness) |
2 mm Low Iron HTAR semi-tempered glass |
| Back Glass (Material / Thickness) |
2 mm Low Iron Printed semi-tempered glass |
| Encapsulate |
PID Free & UV Resistant |
| Junction Box (Protection degree / Material) |
IP68 / Weatherproof PPO |
| Cable & Connector (Protection degree / Type) |
IP68 rated / MC4 compatible |
| Cable Cross-section & Length |
4 mm² & 500 mm |
| Frame |
Anodized Aluminium Alloy |
